Our Products

ecoStorm Hydroshark

The Hydroshark sedimentation plant reliably removes filterable solids (TSS) from the rain runoff. In this way, it protects water bodies and infiltration systems.

For installation in a concrete shaft.

  • cleans by sedimentation with hydrodynamical separators, retention of light substances such as oils
  • underground system, small excavation area
  • no height offset between inlet and outlet
  • easy control and maintenance
  • drainable sediment container

Price on request

  • ecoStorm Hydroshark 750
    Technical Data

    for installation in a concrete shaft DN800

    Drainage area based on
    1. DWA M 153 D 25 (D = 0,35):1.000 m²
    2. DWA M 153 D 24 (D = 0,50):1.500 m²
    3. Trennerlass NRW:1.000 m²

    max. hydraulic load:
    DN150: 18,8 l/s

    Price on request

  • ecoStorm Hydroshark 1000
    Technical Data

    für den Einbau in den Betonschacht DN1000

    Drainage area based on
    1. DWA M 153 D 25 (D = 0,35):2.000 m²
    2. DWA M 153 D 24 (D = 0,50):2.500 m²
    3. Trennerlass NRW:2.000 m²

    max. hydraulic load:
    DN200: 40,4 l/s; DN250: 51,3 l/s

    Price on request

  • ecoStorm Hydroshark 1500
    Technical Data

    for installation in a concrete shaft DN1500

    Drainage area based on
    1. DWA M 153 D 25 (D = 0,35): 4.000 m²
    2. DWA M 153 D 24 (D = 0,50): 5.000 m²
    3. Trennerlass NRW: 4.000 m²

    max. hydraulic load:
    DN300: 98 l/s

    Price on request

  • ecoStorm Hydroshark 2000
    Technical Data

    for installation in a concrete shaft DN2000

    Drainage area based on
    1. DWA M 153 D 25 (D = 0,35):  8.000 m²
    2. DWA M 153 D 24 (D = 0,50):10.000 m²
    3. Trennerlass NRW:  8.000 m²

    max. hydraulic load:
    DN350: 147 l/s; DN400: 220 l/s

    Price on request

  • ecoStorm Hydroshark 2500
    Technical Data

    for installation in a concrete shaft DN2500

    Drainage area based on
    1. DWA M 153 D 25 (D = 0,35):12.000 m²
    2. DWA M 153 D 24 (D = 0,50):15.000 m²
    3. Trennerlass NRW:12.000 m²

    max. hydraulic load:
    DN400: 220 l/s; DN500: 378 l/s

    Price on request

  • ecoStorm Hydroshark 3000
    Technical Data

    for installation in a concrete shaft DN3000

    Drainage area based on
    1. DWA M 153 D 25 (D = 0,35):18.000 m²
    2. DWA M 153 D 24 (D = 0,50):22.000 m²
    3. Trennerlass NRW:18.000 m²

    max. hydraulic load:
    DN500: 378 l/s; DN600: 674 l/s

    Price on request

Ecostep AP90

Item no. 110138

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Aluminium (ALS)
Dowel Distance: 330 mm
Leg Length: 207,5 mm
Colour: blue

Price on request

Ecostep SP90

Item no. 110136

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Steel (MSS)
Dowel Distance: 330 mm
Leg Length: 207,5 mm
Colour: black

Price on request

Ecostep NP90

Item no. 110137

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Stainless Steel 1.4541 (SSS)
Dowel Distance: 330 mm
Leg Length: 207,5 mm
Colour: orange

Price on request

Ecostep A400

Item no. 103964

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Steel (MSS)
Dowel Distance: 328 mm
Leg Length: 230 mm
Colour: black

Price on request

Ecostep A410

Item no. 110091

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Stainless Steel 1.4541 (SSS)
Dowel Distance: 328 mm
Leg Length: 230 mm
Colour: orange

Price on request

Ecostep B300

Item no. 103963

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Steel (MSS)
Dowel Distance: 328 mm
Leg Length: 230 mm
Colour: black

Price on request

Ecostep B310

Item no. 110093

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Stainless Steel 1.4541 (SSS)
Dowel Distance: 328 mm
Leg Length: 230 mm
Colour: orange

Price on request

Ecostep BS320

Item no. 103248

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Steel pipe (MST)
Dowel Distance: 320 mm
Leg Length: 185 mm
Colour: black

Price on request

Ecostep FP301

Item no. 103067

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Steel pipe (MST)
Dowel Distance: 300 mm
Leg Length: 194 mm
Colour: blue

Price on request

Ecostep FP331

Item no. 102087

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Steel pipe (MST)
Dowel Distance: 330 mm
Leg Length: 194 mm
Colour: blue

Price on request

Ecostep FP302

Item no. 103068

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Steel pipe (MST)
Dowel Distance: 300 mm
Leg Length: 192 mm
Colour: blue

Price on request

Ecostep FP332

Item no. 103055

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Steel pipe (MST)
Dowel Distance: 330 mm
Leg Length: 192 mm
Colour: blue

Price on request

Ecostep FP303

Item no. 104036

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Steel pipe (MST)
Dowel Distance: 300 mm
Leg Length: 192 mm
Colour: blue

Price on request

Ecostep FP333

Item no. 104037

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

Core Material: Steel pipe (MST)
Dowel Distance: 330 mm
Leg Length: 202 mm
Colour: blue

Price on request

Ecostep FP301-R

Item no. 112803

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

complete with two locking rings

Core Material: Steel (MSS)
Dowel Distance: 300 mm
Leg Length: 193 mm
Colour: yellow

Price on request

Ecostep A400/G ANCHOR 15.5°

Item no. 104621

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

complete with 2 locking rings

Core Material: Steel (MSS/G)
Dowel Distance: 330 mm
Leg Length: 206 mm
Colour: yellow

Price on request

Ecostep AP90 ANCHOR

Item no. 112331

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

komplett with two locking rings

Core Material: Aluminium (ALS)
Dowel Distance: 330 mm
Leg Length: 197 mm
Colour: yellow

Price on request

Ecostep SP90 ANCHOR

Item no. 112332

single-steps according to EN 13101. Completely covered with plastic for total corrosion protection.

Packing: 600 pcs/crate

Technical Data

complete with two locking rings

Core Material: Steel (MSS)
Dowel Distance: 330 mm
Leg Length: 197 mm
Colour: yellow

Price on request

Dowel Type A/B

Item no. 110228

Dowel made of plastic for easy and safe retrofitting of our manhole steps. Suitable for manhole steps Type A and B.

Packing: 300 pcs/sack

Technical Data

Material: Plastic

Price on request

Dowel Type FP

Item no. 103215

Dowel made of plastic for easy and safe retrofitting of our manhole steps. Suitable for manhole steps Type FP.

Packing: 300 pcs/sack

Technical Data

Material: Plastic

Price on request

Dowel Type ANCHOR

Item no. 104361

Dowel made of plastic for easy and safe retrofitting of our manhole steps. Suitable for manhole steps Type ANCHOR.

Packing: 600 pcs/carton

Technical Data

Material: Plastic

Price on request

ecoLine-a

Above Ground Oil Water Separator according to EN858 und DIN1999 to separate free, non-emulsified oil from water.

The ecoLine-a oil/water separator is designed to seperate free non-water-soluble light liquids (as defined in the German Standard DIN 1999 and the European Standard prEN 858-1) with a maximum specific gravity of 0.959 from water (petroleum by products such as gasoline, diesel and other mineral oils).

ecoLine-a offers a full range of above ground oil water separators from 25gpm (1,5l/s) to 636gpm (40l/s).

Available nominal sizes:
NS1.5, NS03, NS06, NS09, NS12, NS20, NS40

Removal efficiency:
Oil concentration < 5ppm

Price on request

ecoTop

Above ground Oil Water Separator according to EN858 and DIN1999 for the separation of free non-emulsified oil from water.

The ecoTop oil/water separator is designed to separate free non-water-soluble light liquids (as defined in the German Standard DIN1999 and the European Standard prEN 858-1) with a maximum specific gravity of 0.950 from water (petroleum byproducts such as gasoline, diesel and other mineral oils).

The sediment and solids pre-treated runoff is gravity fed or pumped (typically with a positive displacement
or diaphragm type pump) to the gravity separator through a submerged inlet pipe. The separation process relies on the fact, that light fluids have a lower specific gravity than water and thus float on the water surface.

The ecoTop is made of stainless steel 1.4301, pickled and anodized after welding.

Available nominal sizes:
NS03, NS10

Removal efficiency:
Free oil concentration < 5ppm

Price on request

ecoLine-b

Below Ground Oil Water Separator according to EN858 und DIN1999 to separate free, non-emulsified oil from water.

The ecoLine-b oil/water separator is designed to separate non-emulsified light liquids or low-water-soluble fluids with a specific gravity below 0.95 (gasoline, diesel, heating oils and other mineral oils) from effluent discharge. A two-step separation process, gravity separation and removal of small oil particles by coalescing media elements, produces high removal efficiencies.

The ecoLine-b models are made of Stainless Steel Grade 304 and high grade polyethylene and offer a full range of below ground oil water separators from 50gpm (3l/s) to 1100gpm (70l/s).

Available nominal sizes:
NS01, NS03, NS06, NS10, NS15, NS20, NS40, NS50, NS70, NS100

Removal efficiency:
Oil concentration < 5ppm

Price on request

ecoSep

Below Ground Oil Water Separator according to EN858 and DIN1999 for the separation of free non-emulsified oil from water.

The ecoSep oil water separator is designed to separate free non-water-soluble light with a maximum specific gravity of 0.95 from water (petroleum byproducts such as gasoline, diesel and other mineral oils).

The automatic shut-off valve stops the flow from the grit chamber either when the maximum oil storage capacity is reached or when a certain liquid level in the separation chamber is exceeded. In its closed position, the valve is tight up to 50kPa (5m total head) pressure.

With ecoSep you receive a high-grade quality product, that (by proper use) exceeds all guidelines of European, Australian and North American Standards for oil/water separation.

Available nominal sizes:
NG03, NS10, NS20

Removal efficiency:
Free oil concentration < 5ppm

Price on request

ecoStorm plus 400

ecoStorm plus is an affordable stormwater filtration system designed to remove sediments, heavy metals and nutrients.

Surface water runoff contains significant concentrations of heavy metals and other soluble pollutants. Structural Stormwater treatment systems are effective in removing sediments, but do not remove solubles such as heavy metals and nutrients (phosphates and nitrates).

Applications:

  • Treatment of run-off from metal roofs.
  • Surface water runoff from streets, highways and parking lots.
  • Upstream to a rainwater harvesting tank.
  • Stormwater runoff from surface areas generating less than 50gpm (3l/s) treatment flow rate.

Price on request

ecoStorm plus 1000

ecoStorm plus is an affordable stormwater filtration system designed to remove sediments, heavy metals and nutrients.

Surface water runoff contains significant concentrations of heavy metals and other soluble pollutants. Structural Stormwater treatment systems are effective in removing sediments, but do not remove solubles such as heavy metals and nutrients (phosphates and nitrates).

Applications:

  • Treatment of run-off from metal roofs.
  • Surface water runoff from streets, highways and parking lots.
  • Upstream to a rainwater harvesting tank.
  • Stormwater runoff from surface areas generating less than 50gpm (3l/s) treatment flow rate.

Price on request

ecoStorm plus 1500

ecoStorm plus is an affordable stormwater filtration system designed to remove sediments, heavy metals and nutrients.

Surface water runoff contains significant concentrations of heavy metals and other soluble pollutants. Structural Stormwater treatment systems are effective in removing sediments, but do not remove solubles such as heavy metals and nutrients (phosphates and nitrates).

Applications:

  • Treatment of run-off from metal roofs.
  • Surface water runoff from streets, highways and parking lots.
  • Upstream to a rainwater harvesting tank.
  • Stormwater runoff from surface areas generating less than 50gpm (3l/s) treatment flow rate.

Price on request

ecoSep XL

Below Ground Oil Water Separator according to EN858 and DIN1999 for the separation of free non-emulsified oil from water.

The ecoSep XL NG40 is designed to separate non-emulsified light liquids or low-water-soluble fluids with a specific gravity below 0.95 (gasoline, diesel, heating oils and other mineral oils) from effluent discharge. Removal of small oil particles by coalescing media elements, produces high removal efficiencies.

The grit chamber removes solids from the influent, thus ensuring unimpeded functioning of the oil separator itself. The grit trap can be the first concrete tank of a standard two-tank design, or part of a combined single tank solution (grit chamber and separation chamber).

Available nominal size:
NS40 for one unit. Higher flow rates possible (parallel arangement).

Removal efficiency:
Free oil concentration < 5ppm

Price on request

ecoGrease-a

Designed to exceed removal efficiencies <25ppm!
The ecoGrease system separates liquid, coagulating animal and vegetable fat and grease from water prior to discharge into septic or municipally owned sewers.

For the first time, a grease separation technology will allow the consultant, plumber or end user to not only size the system strictly by flow-rate, but also achieve specific effluent removal efficiencies for these pollutants!

The integrated sight glass enables accurate monitoring of accumulated grease levels which determines appropriate disposal intervals.

Fields of application:

Kitchens
Restaurants, hotels
Institutional and processing facilities, …

Available nominal sizes:
NS04, NS07, NS10

Removal efficiency:
Free oil concentration < 5ppm

Price on request

ecoStop® Spill Control

Readily prepared for the installation in a circular precast concrete structure.

The automatic shut-off valve stops the flow from an above-grade area either when the maximum oil storage capacity is reached or when a certain liquid level in the separation chamber is exceeded. In its closed position, the valve is tight up to 0.5 bar.

Components list:

  • Spill Control Valve
  • Float for Spill Control Valve
  • PVC Pipe
  • NBR Gasket for PVC Pipe
  • Mounting Material

Available nominal sizes:
DN100, DN150, DN200

Price on request

ecoWarn

Specially designed warning device for oil water separators
100-240 VAC, 50/60 Hz

Set consists of:

  • Control unit
  • Sensor for detecting high liquid level, 5m cable length
  • Sensor for detecting oil, 5m cable length
  • Cable connector for two sensors
  • Mounting material

→ other warning devices on request

Price on request

Automatic Oil Draw-off Device DN50

The patented “Automatic Oil Draw off Device” (“ADD”) marks a very important development in oil water separator skimmer technology. The ADD automatically and mechanically extracts the refined oil any ecoTECHNIC or third party separator has separated and drains it to a separate container providing pure separated oil which is 99.7 % free of water.

The need for septic truck service is thereby greatly reduced providing the operator with substantial costs savings and it also provides a valuable commodity for resale - pure recycled separated oil containing only 0.3 % water.

Suitable for our ecoLine-a, ecoLine-b and ecoSep-XL as well as for expanding all oil water separator units.

Price on request

Automatic Oil Draw-off Device for ecoTop

The patented “Automatic Oil Draw off Device” (“ADD”) marks a very important development in oil water separator skimmer technology. The ADD automatically and mechanically extracts the refined oil any ecoTECHNIC or third party separator has separated and drains it to a separate container providing pure separated oil which is 99.7 % free of water.

The need for septic truck service is thereby greatly reduced providing the operator with substantial costs savings and it also provides a valuable commodity for resale - pure recycled separated oil containing only 0.3 % water.

Suitable for ecoTop.

Price on request
